Cáp mạng Cat6 UTP - Eight, 305m/cuộn, vỏ màu xanh
Giá bán: 2.550.000 VND / 1 Cuộn
Cáp mạng Cat6 UTP 8 lõi đồng nguyên chất - Eight, 305m/cuộn, vỏ màu xanh
Hãng sản xuất : Eight
Địa điểm bán : Số 99 ngõ 98 Thái Hà, Đống Đa, Hà Nội
Chia sẻ :
Đặt hàng :
Đặt hàng
Cáp mạng Cat6 UTP 8 lõi đồng nguyên chất - Eight, 305m/cuộn, vỏ màu xanh
Description
- Conductor: 23 AWG, copper wires
- Insulation: HDPE (CM/CMG)
- Polyvinyl chloride
- Standard: UL subject 444, CSA TIA/EIA 568B &
- ISO/IEC 11801
- UL Grade : CMX, CM, CMR
- LSZH is available , Armour version available
- ISO9001Certied Manufacturing Plant
Application :
Data communications, Local area networks, Building signaling systems
Specication
- Operating Temperature Range: 20 ~ 50˚C
- Maximum pulling Tension: 70N
- Minimum bending Radius: 4D mm
- Nominal Mutual Capacitance @1KHz: 5.1 nF /100m
- Maximum Capacitance Unbalance: 330 pF /100m
- Maximum Delay @1KHz: 570 ns /100m
- Maximum Delay Skew: 45 ns /100m
- Maximum Conductor DC Resistance @20 ˚C: 9.38 Ω /100m
- Maximum DCR Unbalance @20 ˚C: 5%
- Maximum Operating Voltage(VRMS): 80V
- Characteristics Impedance: 100 Ω
- Insulation: HDPE (CM/CMG)
- Polyvinyl chloride
- Standard: UL subject 444, CSA TIA/EIA 568B &
- ISO/IEC 11801
- UL Grade : CMX, CM, CMR
- LSZH is available , Armour version available
- ISO9001Certied Manufacturing Plant
Application :
Data communications, Local area networks, Building signaling systems
Specication
- Operating Temperature Range: 20 ~ 50˚C
- Maximum pulling Tension: 70N
- Minimum bending Radius: 4D mm
- Nominal Mutual Capacitance @1KHz: 5.1 nF /100m
- Maximum Capacitance Unbalance: 330 pF /100m
- Maximum Delay @1KHz: 570 ns /100m
- Maximum Delay Skew: 45 ns /100m
- Maximum Conductor DC Resistance @20 ˚C: 9.38 Ω /100m
- Maximum DCR Unbalance @20 ˚C: 5%
- Maximum Operating Voltage(VRMS): 80V
- Characteristics Impedance: 100 Ω
| Frequ ency MHz | Atten uation (dB/ 100m) | Next (dB) | Return Loss (dB) | ACR (dB) | Power Sum | ||
| Next (dB) | ELF EXT (dB/ 100m) | ACR (dB) | |||||
| 1 | 2 | 74.3 | 20 | 72.3 | 72.3 | 63.8 | 70.3 |
| 4 | 3.8 | 65.3 | 23 | 61.5 | 63.3 | 51.8 | 59.5 |
| 8 | 5.3 | 60.8 | 24.5 | 55.4 | 58.8 | 45.7 | 53.4 |
| 10 | 6 | 59.3 | 25 | 53.4 | 57.3 | 43.8 | 51.4 |
| 16 | 7.6 | 56.2 | 25 | 48.7 | 54.2 | 39.7 | 46.7 |
| 20 | 8.5 | 54.8 | 25 | 46.3 | 52.8 | 37.8 | 44.3 |
| 25 | 9.6 | 53.3 | 24.3 | 43.8 | 51.3 | 35.8 | 41.8 |
| 31.3 | 10.7 | 51.9 | 23.6 | 41.2 | 49.9 | 33.9 | 39.2 |
| 62.5 | 15.4 | 47.4 | 21.5 | 32 | 45,4 | 27.9 | 30 |
| 100 | 19.8 | 44.3 | 20.1 | 24.5 | 42.3 | 23.8 | 22.5 |
| 155 | 25.2 | 41.5 | 18.8 | 16.3 | 39.5 | 20 | 14.3 |
| 200 | 29 | 39.8 | 18 | 10.8 | 37.8 | 17.8 | 8.8 |
| 250 | 32.9 | 38.3 | 17.3 | 5.5 | 36.3 | 15.8 | 3.5 |
